S8 DSP
Digital Interface Processor
Hertz S8 DSP is the perfect solution for integrating any OEM system to your car, motorcycle, and boat! A distilled essence of technology at the service of the highest audio quality in a corrosion-free case cast in metal and composite materials
The S8 DSP process has obtained the HI-Res certification from the Japan Audio Society - which acknowledges the extreme level of audio performance achieved.
The 32-bit DSP offers maximum freedom of configuration to the specialist through the 6 high/low-level analog input channels, one digital coaxial input, and 8 output channels. The SPDIF coaxial input is best for digital connection with Hi-Res player, a solution that allows for maximum listening quality. For every one of the eight output channels we have a level of control, the 15-pol parametric equalizer, time delays, and crossover filter available. The 7-band parametric equalizer of the input signal allows obtaining a flat response from OEM sources, which often have an exaggerated emphasis on the low frequency.
Power Supply:
| Nominal power supply voltage / fuse: | 7÷20 VDC / 1A |
| Pulse operating voltage: | 5÷24 VDC |
| Idling Current: | 0.34 A |
| Remote IN: | 6÷ 20 VDC (10 mA) |
| Remote OUT: | 4÷ 20 VDC (150 mA) |
Signal Stage:
| Distortion – THD @ 1 kHz, 1 VRMS Output: | 0.004% |
| Bandwith @ -3 dB: | 10 Hz ÷ 40 kHz |
| S/N ratio @ A weighted, 4 V Output, 1 V MASTER input: | 100 dBA |
| S/N ratio @ A weighted, 4 V Output, DIGITAL IN input: | 112 dBA |
| Channel Separation @ 1 kHz: | 97 dBA |
| Input Impedance: | 10 k |
| Max output level 0,1% THD: | 4 V |
Inputs Stage:
| Low level (Pre): | Ch1 ÷ Ch6;input/output matrix routing |
| Hi level (Speaker In): | Ch1 ÷ Ch6 |
| Digital: | 1 x Coaxial S/PDIF; Max 96 kHz / 24 bit; Extra Gain +3dB, +6dB |
Output Stage:
| Low Level (Pre): | Ch1 ÷ Ch8 |
| Output Equalizer: | 15 poles Paragraphic EQ |
Connection:
| From / to personal computer: | 1 x micro USB |
| Bluetooth data connectivity (no audio): | BT 5.0 (BLE) |
Crossover:
| Filter Type: | Full/ Hi pass/ Low Pass / Band Pass |
| Filter mode and slope: |
Linkwitz @ 12 / 24 dB Butterwort @ 6/12/18/24/30 dB Bessel @ 6/12/18/24/30 dB |
| Crossover Frequencies: | 20 ÷ 20k Hz (120 step) |
| Phase Control: | 0 / 180 |
General:
| Memory Presets: | 4 x Presets |
| Memory Presets Selection: | Through the control software or by wire |
Time Alignment:
| Distance: | 0 ÷ 471,5cm / 0 ÷ 185,5 inches |
| Delay: | 0 ÷ 13,58 m |
| Step: | 0,002 ms, 0,7 cm / 0,27 in |
General Requirements:
| PC Connections: | 1xUSB 1,1 / 2,0 / 3,0 Compatible or Bluetooth 5.0 BLE |
| Minimum Mobile Device requirements: | Android OS 7 or later, iOS 12 or later |
| Video Resolution with screen resize: | min 1024 x 600 |
